Description
- 8.3MP, Max. 3840 x 2160 @20fps • 2.8mm fixed lens
- True WDR 120dB
- IR up to 100ft
- 3-Axis rotate
- Support H.265, H.265+
- Support on-board storage up to 128GB • IP67, IK10
- DC 12V, POE
- Video Content Analytic
| Camera | |
| Image Sensor | 1 /2.5" Progressive Scan CMOS |
| Min. Illumination | Color: 0.01 lux @(F1.2, AGC ON), 0 lux with IR |
| Shutter Speed | 1/3 s to 1/10,000 s |
| Lens | 2.8mm @ F2.0, horizontal field of view: 102° (4mm optional) |
| Lens Mount | M12 |
| Day &Night | IR cut filter with auto switch |
| DNR | 3D DNR |
| Wide Dynamic Range | 120dB |
| P&T rotation | Pan: 0º to 355º, Tilt: 0º to 75º, Rotation: 0º to 355º |
| Compression Standard | |
| Video Compression | Main stream: H.265/H.264 |
| Sub stream: H.265/H.264/MJPEG | |
| Third stream: H.265/H.264 | |
| H.264 Type | Main Profile/High Profile |
| H.264+ | Support |
| H.265 Type | Main Profile |
| H.265+ | Support |
| Video Bit Rate | 32 Kbps to 16 Mbps |
| Dual streams | Support |
| Image | |
| Max. Resolution | 3840 x 2160 |
| Frame Rate | 50Hz: 20 fps (3840 x 2160), 25 fps (2560 x 1920, 2560 x 1440, 1920 x 1080, 1280 x 720) |
| 60Hz: 20 fps (3840 x 2160), 30 fps (2560 x 1920, 2560 x 1440, 1920 x 1080, 1280 x 720) | |
| Image Setting | Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser |
| BLC | Support, zone configurable |
| ROI Codec | Support 1 fixed region for each stream, and face dynamic tracking |
| Network | |
| Network Storage | NAS (Support NFS,SMB/CIFS), ANR |
| Alarm Trigger |
Line Crossing, Intrusion Detection, Motion detection, Tampering alarm, Network disconnect, IP address conflict, Storage exception |
| Protocols |
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| General |
One-key reset, Flash-prevention, dual stream, heartbeat, mirror, password protection, privacy mask, watermark, IP address filtering, Anonymous access |
| Standard | ONVIF (PROFILE S, PROFILE G), PSIA, CGI, ISAPI |
| Interface | |
| Communication Interface | 1 RJ45 10M/100M Ethernet port |
| On-board storage | Built-in Micro SD/SDHC/SDXC slot, up to 128GB |
| General | |
| Operating Conditions | -22 ºF – 140 ºF, Humidity 95% or less (non-condensing) |
| Power Supply | DC12V ± 25%, PoE (802.3af, class 3)) |
| Power Consumption | Max. 9W |
| IR Range | Approx. 100ft |
| Ingress Protection | IP67 |
| Impact Protection | IK10 |
| Dimensions | 4.4” x 3.2” |
| Weight | 1.1lbs |
