Description
Optics
- High quality image with 8MP
- Day/night functionality
- Smart IR , up to 30 m (98 ft) IR distance
- Optical glass window with higher light transmittance
- IR anti-reflection window to increase the infrared transmittance
- 2D/3D DNR (Digital Noise Reduction)
- Ultra 265, H.265, H.264, MJPEGTriple streams
- ROI (Region of Interest)
- ONVIF Conformance
- Wide temperature range: -30°C to 60°C (-22°F to 140°F)
- Wide voltage range of ±25%
- IP67
- 3-Axis
Specifications
|
Camera |
|||||||||
|
Sensor |
1/3", 8.0 megapixel, progressive scan, CMOS |
||||||||
|
Lens |
2.8mm@F2.0 |
|
|||||||
|
DORI Distance |
Lens |
Detect(m) |
Observe(m) |
Recognize(m) |
Identify(m) |
||||
|
2.8mm |
84 |
33.6 |
16.8 |
8.4 |
|||||
|
4.0mm |
120 |
48 |
24 |
12 |
|||||
|
Angle of View (H) |
112.7° |
86.5° |
|||||||
|
Angle of View (V) |
60.1° |
44.1° |
|||||||
|
Angle of View (D) |
146.5° |
106.4° |
|||||||
|
Adjustment angle |
Pan: 0°~360° |
Tilt: 0°~90° |
Rotate: 0°~360° |
||||||
|
Shutter |
Auto/Manual, 1~1/100000 s |
||||||||
|
Minimum Illumination |
Colour: 0.05 Lux (F2.0, AGC ON) 0 Lux with IR on |
||||||||
|
Digital noise reduction |
2D/3D DNR |
||||||||
|
Day/Night |
IR-cut filter with auto switch (ICR) |
||||||||
|
S/N |
>56dB |
||||||||
|
IR Range |
Up to 30m (98 ft) IR range |
||||||||
|
Wavelength |
850nm |
||||||||
|
IR On/Off Control |
Auto/Manual |
||||||||
|
Defog |
Digital Defog |
||||||||
|
WDR |
120dB |
||||||||
|
Video |
|||||||||
|
Video Compression |
Ultra 265, H.265, H.264, MJPEG |
||||||||
|
H.264 code profile |
Baseline Profile, Main Profile |
||||||||
|
Frame Rate |
Main Stream:8MP (3840*2160): Max. 20 fps;5MP(2944*1656): Max. 30 fps; 4MP(2560*1440): Max. 30 fps; 2MP(1920*1080): Max. 30 fps Sub Stream:720P (1280*720): Max. 20 fps Third Stream:4CIF (704*576): Max. 20 fps |
||||||||
|
Video Bit Rate |
128 Kbps~16 Mbps |
||||||||
|
OSD |
Up to 4 OSDs |
||||||||
|
Privacy Mask |
Up to 4 areas |
||||||||
|
ROI |
Up to 2 areas |
||||||||
|
Motion Detection |
Up to 4 areas |
||||||||
|
Image |
|||||||||
|
White Balance |
Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 |
||||||||
|
Digital noise reduction |
2D/3D DNR |
||||||||
|
Smart IR |
Support |
||||||||
|
Flip |
Normal/Vertical/Horizontal/180° |
||||||||
|
Dewarping |
NA |
||||||||
|
HLC |
Supported |
||||||||
|
BLC |
Supported |
||||||||
|
Smart |
|||||||||
|
Behavior Detection |
Intrusion, Human Body Detection, Motion detection, Tampering alarm |
||||||||
|
Network |
|||||||||
|
Protocols |
IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SSL,QoS |
||||||||
|
Compatible Integration |
ONVIF(Profile S, Profile T), API |
||||||||
|
Client |
EZStation EZView EZLive |
||||||||
|
Web Browser |
Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below |
||||||||
|
Plug-in free live view: Chorme 57.0+, Firefox 58.0+, Edge 16+, Safari 11+ |
|||||||||
|
Interface |
|||||||||
|
Network |
10/100M Base-TX Ethernet |
||||||||
|
Certifications |
|||||||||
|
Certifications |
CE: EN 60950-1 UL: UL60950-1 FCC: FCC Part 15 |
||||||||
|
General |
|||||||||
|
Power |
12 V DC±25%, PoE (IEEE802.3 af) |
||||||||
|
Power consumption: Max 5.5W |
|||||||||
|
Dimensions (L × W × H) |
167.3×62.9×62.7mm (6.6”×2.5”×2.5”) |
||||||||
|
Net Weight |
0.45kg (0.99lb) |
||||||||
|
Material |
Metal |
||||||||
|
Working Environment |
-30°C ~ +60°C (-22°F ~ 140°F), Humidity: ≤95% RH(non-condensing) |
||||||||
|
Strorage Environment |
-30°C ~ +60°C (-22°F ~ 140°F), Humidity: ≤95% RH(non-condensing) |
||||||||
|
Surge Protection |
2KV |
||||||||
|
Ingress Protection |
IP67 |
||||||||
|
Reset Button |
Supported |
||||||||
