Description
- Day/night functionality
- Up to 120dB WDR (Wide Dynamic Range)
- Smart IR, up to 30m (98ft) IR distance
- Ultra 265, H.264, MJPEG
- Triple streams
- ONVIF Conformance
- Wide temperature range: -30°C to 60°C (-22°F to 140°F)
- Wide voltage range of ±25%
- Micro SD, up to 256 GB
- Built-in Mic
- 2KV surge protection designed for network interface
- IP67
- 3-Axis
Specifications
|
Camera |
|||||||||
|
Sensor |
1/3", 4.0 megapixel, progressive scan, CMOS |
||||||||
|
Lens |
2.8mm@F2.0 |
4.0mm@F2.0 |
|||||||
|
DORI Distance |
Lens (mm) |
Detect (m) |
Observe (m) |
Recognize (m) |
Identify (m) |
||||
|
2.8 |
63.0 |
25.2 |
12.6 |
6.3 |
|||||
|
4.0 |
90.0 |
36.0 |
18.0 |
9.0 |
|||||
|
Angle of view(H) |
107.8° |
82.0° |
|||||||
|
Angle of View (V) |
57.0° |
41.6° |
|||||||
|
Angle of View (O) |
140.1° |
100.9° |
|||||||
|
Adjustment angle |
Pan: 0° ~ 360° |
Tilt: 0° ~ 80° |
Rotate: 0° ~ 360° |
||||||
|
Shutter |
Auto/Manual, 1 ~ 1/100000s |
||||||||
|
Minimum Illumination |
Colour:0.01Lux (F2.0, AGC ON) 0Lux with IR on |
||||||||
|
Day/Night |
IR-cut filter with auto switch (ICR) |
||||||||
|
Digital noise reduction |
2D/3D DNR |
||||||||
|
S/N |
>56dB |
||||||||
|
IR Range |
Up to 30m (98ft) IR range |
||||||||
|
Wavelength |
850nm |
||||||||
|
IR On/Off Control |
Auto/Manual |
||||||||
|
Defog |
Digital Defog |
||||||||
|
WDR |
120dB |
||||||||
|
Video |
|||||||||
|
Video Compression |
Ultra 265, H.265, H.264, MJPEG |
||||||||
|
H.264 code profile |
Baseline profile, Main Profile |
||||||||
|
Frame Rate |
Main Stream: 4MP (2688*1520), Max 30fps; 4MP (2560*1440), Max 30fps; 3MP (2304*1296), Max 30fps; 1080P(1920*1080),Max30fps Sub Stream: 720P (1280*720), Max 30fps; Third Stream: 4CIF (704*576), Max 30fps |
||||||||
|
Video Bit Rate |
128 Kbps~16 Mbps |
||||||||
|
OSD |
Up to 4 OSDs |
||||||||
|
Privacy Mask |
Up to 4 areas |
||||||||
|
ROI |
Up to 4 areas |
||||||||
|
Motion Detection |
Up to 4 areas |
||||||||
|
Image |
|||||||||
|
White Balance |
Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 |
||||||||
|
Digital noise reduction |
2D/3D DNR |
||||||||
|
Smart IR |
Support |
||||||||
|
Flip |
Normal/Vertical/Horizontal/180° |
||||||||
|
Dewarping |
NA |
||||||||
|
HLC |
Supported |
||||||||
|
BLC |
Supported |
||||||||
|
Audio |
|||||||||
|
Audio Compression |
G.711 |
||||||||
|
Suppression |
Supported |
||||||||
|
Sampling Rate |
8KHZ |
||||||||
|
Storage |
|||||||||
|
Edge Storage |
Micro SD, up to 256 GB |
||||||||
|
Network Storage |
ANR |
||||||||
|
Smart |
|||||||||
|
Behavior Detection |
Intrusion, Human Body Detection, Motion detection, Tampering alarm, Audio Detection |
||||||||
|
Network |
|||||||||
|
Protocols |
IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SSL |
||||||||
|
Compatible Integration |
ONVIF (Profile S, Profile G, Profile T), API |
||||||||
|
Client |
EZStation EZView EZLive |
||||||||
|
Web Browser |
Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below |
||||||||
|
Plug-in free live view: Chorme 57.0+, Firefox 58.0+, Edge 16+, Safari 11+ |
|||||||||
|
Interface |
|||||||||
|
Network |
1 RJ45 10M/100M Base-TX Ethernet |
||||||||
|
Built-in Mic |
Supported |
||||||||
|
Certifications |
|||||||||
|
Certifications |
CE: EN 60950-1 UL: UL60950-1 FCC: FCC Part 15 |
||||||||
|
General |
|||||||||
|
Power |
DC 12V±25%, PoE (IEEE 802.3af) |
||||||||
|
Power consumption: Max 5.5W |
|||||||||
|
Dimensions (Ø x H) |
Φ118 x 96mm (Φ4.6” x 3.8”) |
||||||||
|
Net Weight |
0.33kg (0.73lb) |
||||||||
|
Material |
Metal + Plastic |
||||||||
|
Operating Conditions |
-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) |
||||||||
|
Strorage Environment |
-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) |
||||||||
|
Surge Protection |
2KV |
||||||||
|
Ingress Protection |
IP67 |
||||||||
